所有劲拓达产品指南
通用 主要特性 Max. temperature limit: -40...+250°C (see table for thermocouple cable used) Reference tolerances: Standards IEC 584.2 class 2 for type J, K: ± 2.5°C (-40...+333°C) Cable to DIN standard
放大输出 - 通用 主要特性 Temperature limits: -40 ... +350°C for type T -40 ... +750°C for type J -40 ... +900°C for type E -40 ... +1000°C for type K (see table for sheath diameters) Tolerance (IEC standard 584.2/Class 2): for T: ± 1°C (-40 ... +133°C) ± 0.0075 [t] (t > +133°C) for J, E, K: ± 2,5°C (-40 ... +333°C) ± 0.0075 [t] (t > +333°C) Ceramic insulation of the thermocouple element
可互换的 MgO插件 - 工业过程和熔炉 主要特性 Amplified output signal Temperature limits: -40 ... + 350°C for type T -40 ... + 550°C for type J -40 ... + 600°C for type E -40 ... +1050°C for type K (see table for sheath diameters) Tolerance: UNI 7938, IEC standards 584.2 Class 1: for type T: ± 0,5° C (- 40 ... + 125° C) ± 0.004 [t] (t > + 375° C) for type J, E, K: ± 1.5° C (- 40 ... + 375° C) ± 0.004 [t] (t > + 375° C)
